UXR1104B Infiniium UXR Series Oscilloscopes: 110 GHz, 4 Channels

Features • 110 GHz bandwidth • 500 Mpts memory depth per channel, upgradable to 2 Gpts per channel • 256 GSa/s sampling rate on all channels • 160 MHz DDC, upgradable to 2.16 GHz DDC • 160 MHz RTSA, upgradable to 320 MHz RTSA • High-resolution 10-bit analog-to-digital converter (ADC) • Lower background noise and measurement background jitter • High effective number of bits (ENOB) across all supported bandwidths • Optional calibration module N2125A allows you to perform self-calibration on-site • Includes high-speed SDA and clock recovery functions• Includes user-defined functions • Includes InfiniiSim Basic, which can easily compensate for channel loss using a module model • Includes PrecisionProbe/PrecisionCable, helping to quickly characterize probe or cable loss
