TDS6804B Oscilloscope

Key Features and Functions TDS6000B Series instruments are high performance solutions for verifying, debugging, and characterizing sophisticated electronic designs. The series features exceptional signal acquisition performance, operational simplicity, and open connectivity to the design environment. Classic analog-style controls, a large touch-sensitive display, and graphical menus provide intuitive control. Open access to the Windows operating system enables unprecedented customization and extensibility. Key features include: 8 GHz bandwidth and 20 GS/s real time sampling rate, TDS6804B 6 GHz bandwidth and 20 GS/s real time sampling rate, TDS6604B Enhanced Bandwidth capability that, when enabled, applies Digital Signal Process (DSP) filters that can extend the bandwidth and flatten the passband. Enhanced Bandwidth provides a matched response across enabled channels when they are at maximum sample rate.Record lengths up to 32,000,000 samples, depending on model and option Up to 2.5% DC vertical gain accuracy Four input channels (each with 8-bit resolution), auxiliary trigger input and output Sample, envelope, peak-detect, high-resolution, waveform database, and average acquisition modes Full programmability, with an extensive GPIB-command set and a messagebased interface Trigger types include edge, logic, pulse (may be logic qualified), selectable for both A and B trigger events, and at up to 7 GHz analog bandwidth, depending on the model. Window trigger mode triggers as the trigger source passes into or out of a defined window. Triggers can be logic qualified. Setup and hold trigger mode triggers when a logic input changes state inside of the setup and hold times relative to the clock. Trigger jitter is as low as 1.5 ps RMS. You can trigger on a glitch or runt of less than 250 ps Powerful built-in measurement capability, including histograms, automatic measurements, eye pattern measurements and measurement statistics A large 10.4 inch (264.2 mm) high resolution XGA color display that supports color grading of waveform data to show sample density MultiView Zoom to view and compare up to four zoom areas at a time. Lock and manually or automatically scroll up to four zoom areas An intuitive, graphical user interface (UI), with online help that is built in and available on screen Internal, removable disk storage Wide array of probing solutions
