E5061B ENA Vector Network Analyzer

Features And Specifications Source output level: -45 to +10 dBm (at 5 Hz to 3 GHz) Dynamic range: >120 dB (at 1 MHz to 3 GHz, IFBW = 10 Hz) Trace noise: 5 mdBrms (IFBW=3 kHz/Auto) 1 MΩ input: Gain-phase test port, 1 MΩ // 30 pF DC bias source: 0 to ±40 Vdc, max. 100m Adc, sweepable Frequency stability (CW accuracy): ±7 ppm ±1 mHz (standard) Number of channels/traces: 4-channel/4-trace Measured number of points per sweep: User definable from 2 to 1601 IFBW: 1 Hz to 300 kHz, plus IFBW Auto mode (Option 3L3/3L4/3L5)
