N6781A Two-Quadrant SMU for Battery Drain Analysis, 20 V

Highlights Output Ratings: voltage: up to 20 V current: up to ±3 A power: 20 W Programming Accuracy (at 23°C ± 5°C after 30 minute warmup; applies from min. to max. program): voltage, 20 V range: 0.025% + 1.8 mV voltage, 6 V range: 0.025% + 600 µV current, 3 A and 1 A ranges: 0.04% + 300 µA current, 300 mA range: 0.03% + 150 µA Transient Response: < 30 mV of droop in response to 0.15A / µs current transients Measurement Accuracy (at 23°C ± 5°C): voltage, 20 V range: 0.025% + 1.2 mV* current, 3 A range: 0.03% + 250 µA* current, 100 mA range: 0.025% + 10 µA* current, 10 µA range: 0.025% + 8 nA
