Name：Keithley 2611A

OVERVIEW The Keithley 2611A SourceMeter is used as either a bench-top I-V characterization tool or as a building block component of multi-channel I-V test systems. For bench-top use, the Keithley 2611A SourceMeter features an embedded TSP® Express Software Tool that allows users to quickly and easily perform common I-V tests without programming or installing software. For system level applications, the Keithley 2611A SourceMeter's Test Script Processor (TSP®) architecture along with new capabilities such as parallel test execution and precision timing provide the highest throughput in the industry to lower the cost of test. Features and Specifications of the Keithley 2611A SourceMeter include: Single-Channel System SourceMeter Instrument Combines a power supply, true current source, DMM, arbitrary waveform generator, V or I pulse generator with measurement, electronic load, and trigger controller - all in one instrument Backward code compatible to Series 2600 System SourceMeter® Instruments for drop-in replacement TSP® Express software tool for Quick and Easy I-V Test Precision timing and channel synchronization (<500ns) Parallel test execution for unmatched throughput 20,000 rdg/s provides faster test times and ability to capture transient device behavior Family of products offers wide dynamic range: 1fA to 10A and 1µV to 200V TSP-Link® bus allows up to 32 units/64 channels of channel expansion per GPIB or IP address Test Script Processor (TSP®) runs complete test programs (scripts) in the instrument for unparalleled system automation USB port for saving data and test scripts LXI Class C compliance provides high speed data transfer and enables quick, easy remote testing, monitoring, and troubleshooting
