Name：THORLABS PAX1000IR2/M

Optical Parameters(a) Wavelength Range: 900 nm - 1700 nm Dynamic Range: -60 dBm to +10 dBm (10-6 mW to 10 mW) Sampling Rate - Default(b): 30 Samples/s - Maximum (c): 400 Samples/s Measurable SOP(d): Entire Poincaré Sphere Azimuth Accuracy(e): ±0.25° Ellipticity Accuracy: ±0.25° DOP(f) Accuracy: ±1.0% Free Space Aperture: Ø3 mm Input Fiber Connector: FC/PC Accepted by Included Ø12 mm Collimatorg Included Ø12 mm Collimator(g): F240FC-C Maximum Input Beam Divergence: 2° Warm-Up Time for Rated Accuracy: 15 min
