Name：Fluke 5500A

Specifications The Fluke 5500A is a Multifunction Calibrator used in calibration laboratories and applications that require precision sources of voltage and current. It sources DC and AC Volts as well as DC and AC current. It simulates power with phase control, resistance, capacitance, thermocouples and RTDs. Voltage DC Range: 0 to ±1020V Best 1 Year Specification: ±50 ppm of setting Current DC Range: 0 to ±11A Best 1 Year Specification: ±0.01% of setting Resistance Range: 0 to 3.29.999 MΩ Best 1 Year Specification: ±0.009% of setting Voltage AC Range: 1 mV to 1020V, 10 Hz to 500 kHz.
