Name：Keysight UXR0704B

Highlights 70 GHz bandwidth and upgradable to 110 GHz of real-time oscilloscope bandwidth 500 Mpts of memory per channel included and upgradable to 2 Gpts of memory per channel 256 GSa/s sample rate on all channels 160 MHz DDC included and upgradable to 2.16 GHz DDC 160 MHz RTSA included and upgradable to 320 MHz RTSA Optional configurable mmWave extension bandwidth window up to 30 GHz High-definition 10-bit analog-to-digital converter (ADC) The industry’s lowest noise and jitter measurement floor The industry’s highest ENOB at all supported bandwidth Optional calibration module N2126A for on-site self-calibration High-speed SDA and Clock Recovery included User-defined functions included InfiniiSim Basic included to simply compensate for the channel loss with one block model PrecisionProbe/PrecisionCable included helping quickly characterize the probe or cable loss
