Name：Coherent WaveMaster

Product Features The WaveMaster collects signals via an optical fiber sampling head, eliminating the need for optical path alignment. Its spectral range is 380-1095nm, with an absolute wavelength accuracy of 0.005nm and a resolution of 1pm, capable of measuring laser repetition rates ranging from single-shot pulses to continuous wave. In addition, the product’s maximum optical pulse width varies at different wavelengths—2nm at 400nm, 3nm at 600nm, and 5nm at 1000nm. The minimum optical power is 20μW (continuous wave) at 632nm and 2mJ (pulse) at 1064nm, while the maximum optical power is 100mW (continuous wave) at 632nm and 100mJ (pulse) at 1064nm.
